| Standards | 60mm backset single latch & 50&50mm mortise double latch |
| Power Requirement | 4 AAA Alkaline Batteries |
| Unlocking method | 1.Fingerprint 2.IC card 3.Password 4.Metal key |
| Password quantity | 300 pcs |
| IC Card quantity | 300 pcs |
| Card type | Mifare card |
| Fingerprprint quantity | 300 pcs |
| FAR | <0.001% |
| FRR | <1% |
| Dimensions | 236 × 58 × 21mm(9.3×2.3×0.8'') |
| Door thickness | 38-50mm |
| Device Weight | 1.88g(4.1oz) |
| Working voltage | 4.0-7.0v |
| Static current) | ≤20μA |
| Dynamic current | ≤200mA |
| Standard Carton Packing Info | |||
| Model | Quantity | Weight | Dimension(cm) |
| FL-1 | 10pcs | 21KG | 61.5×37.7×36.5(cm) |
| 1set Packing Info | |||
| FL-1 | 1set | 2KG | 35×20×15(cm) |
